RTC prescaler load register low (RTC_PRLL)
Address offset: 0x0C
Write only (see Section 16.3.4 on page 390 )
Reset value: 0x8000
Real-time clock (RTC)
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
PRL[15:0]
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
w
Bits 15:0 PRL[15:0]: RTC prescaler reload value low
These bits are used to define the counter clock frequency according to the following formula:
f TR_CLK = f RTCCLK /(PRL[19:0]+1)
Note:
16.4.4
If the input clock frequency (f RTCCLK ) is 32.768 kHz, write 7FFFh in this register to get a
signal period of 1 second.
RTC prescaler divider register (RTC_DIVH / RTC_DIVL)
During each period of TR_CLK, the counter inside the RTC prescaler is reloaded with the
value stored in the RTC_PRL register. To get an accurate time measurement it is possible to
read the current value of the prescaler counter, stored in the RTC_DIV register, without
stopping it. This register is read-only and it is reloaded by hardware after any change in the
RTC_PRL or RTC_CNT registers.
RTC prescaler divider register high (RTC_DIVH)
Address offset: 0x10
Reset value: 0x0000
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RTC_DIV[19:16]
Reserved
r
r
r
r
Bits 15:4 Reserved
Bits 3:0 RTC_DIV[19:16]: RTC clock divider high
RTC prescaler divider register low (RTC_DIVL)
Address offset: 0x14
Reset value: 0x8000
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
RTC_DIV[15:0]
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
r
Bits 15:0 RTC_DIV[15:0]: RTC clock divider low
